是噴霧干燥裝置中使霧化介質獲得高能量、高速度的部件，也是對霧化效率和霧化過程穩定性起重要作用的關鍵部件。
WRG高速離心霧化器 WRG High Speed Centrifugal Atomizer
概述 Descriptions
該霧化器是噴霧干燥裝置中使霧化介質獲得高能量、高速度的部件，也是對霧化效率和霧化過程穩定性起重要作用的關鍵部件。它由電動機通過聯軸器帶動大齒輪,大齒輪與轉動軸上的小齒輪嚙合，經過一級增速后的齒輪軸帶動二級大齒輪實現霧化盤的高速旋轉。當料液進入離心霧化器的進料管，通過料液分配盤均勻地流入高速旋轉的噴霧盤中，料液即被噴成極小的霧化液滴，使料液表面積大大增加，與干燥室內的熱空氣接觸，水分迅速蒸發，能在極短的時間內干燥為成品。
The atomizer is a spray drying device to make the atomizing medium to obtain high-energy, high-speed components, also it play an important role on the atomization efficiency and stability .It is driven by the motor through a large gear coupling, large gear and the rotating shaft of the small gear meshing, after a growth gear shaft driven two large gear to achieve high-speed rotation of the atomization disk. When the feed liquid into the centrifugal atomizer feed pipe, through the liquid distribution plate ,liquid enter into the high-speed rotation of the spray tray, the liquid is sprayed into a very small atomized droplets, the liquid surface area greatly increased, contact with hot air in drying chamber, rapid evaporation of water in a very short period of time .
特點 Features
齒輪傳動在物料進料量波動時，轉速恒定，機械效率較高；
采用長懸臂結構，使主軸運行時可實現“自動對中”效果，減少主軸和霧化盤的振動。
設置浮動軸承，使撓性軸實現三支點支撐，實現軸系迅速越過臨界轉速。
合理布置支承固定位置，將固定支承位置布置于節點位置，減少軸系的振動載荷。
Speed constant and high mechanical efficiency gear transmission in the material feed rate fluctuations;
Long cantilever structure make "automatic centering" effect, reducing the spindle and atomization disk vibration.
Floating bearing make three fulcrum supports for flexible shaft, The Designing can achieve rapid cross-critical shaft speed.
Reasonably arranged support fixed position, the location of the fixed support position in the node to reduce the vibration load shaft
結構示意圖 Sketch of Oven
