密閉輸送系統：
針對堆積密度比較小，易產生粉塵飛揚、對人體和環境有毒有害的粉體，采用手套箱卸料系統是**的選擇。
手套箱卸料系統的特點： ◆結構簡單緊湊，操作方便 ◆體積小，可移動，適用范圍廣 ◆在整個卸料過程中，全密閉操作，操作人員不和物料有任何接觸 ◆空料袋集中回收，防止袋內殘余物料外泄 ◆與集塵系統配套使用，徹底杜絕粉塵 ◆可采用N2保護，應用于防爆環境 主要技術參數： ◆手套箱材質：304、316L或碳鋼 ◆手套口直徑：?160mm ◆手套口高度：1100 mm ◆料倉的容積：根據客戶需求定制 ◆手套的材質：氯丁橡膠、天然橡膠 ◆手套箱外形尺寸與規格： 單倉門：1000×700×1500 雙倉門：2000×700×1500 可根據客戶要求定制
Glove-box discharging system
Glove-box discharging system would be the best choice referring to powder with low accumulation density and harmfulness to human body and environment.
Main characteristics
Simple and compact configuration and easy operation;
Small size, good mobility and wide application;
Airtight processing to ensure that the operator is separated from materials;
Recovery of used big bag avoiding leaking out of remnant;
Applied with dust-collecting system to completely avoiding dust pollution;
Nitrogen is used in explosion-proofing.
Pneumatic vacuum conveyer
Glove box
Discharging platform
Discharging materials holder
Main parameters
Glove box materials: 304,316L or carbon steel;
Glove diameter: ?160mm;
Glove height: 1,100 mm;
Silo volume: customized according to customer’s demand
Glove material: chloroprene rubber and natural rubber;
Glove-box dimensions and specifications:
Single port: 1000×700×1500
Double ports: 2000×700×1500
customized according to customer’s demand
