旋轉閥BZGFWF
直接聯系
東莞市凌聚機械有限公司
廣東
面議
凌聚
旋轉閥BZGFWF
2019
BZGFWF標準型旋轉閥/關風機
● 適用于≤2kg/cm2系統壓力或壓差
● 能定量供料
● 法蘭標準DIN PN10 ANSl150lbs
● 設置排氣口 (正壓輸送時選用)將葉輪旋轉帶出的高壓氣體通過排 氣口送至排氣裝置，提高填充效率
● 軸承外置式安裝、經久耐用、性能優異
● 提供鏈驅動、直聯驅動多種安裝方式
● 根據需求配置減速機電機
● 材質主要有：碳鋼、鑄鋼、鑄鐵、不銹鋼系列等
BZGFWF
Pressure Range: ≤2 bar. system and different pressure
Main Material: Carbon Steel. Cast Steel, Stainless Steel
Drive Mode: Direct Drive/Chain Drive
Ffange Standard: DfN PN10 ANSf 150lbs
Specification:
1. Body vent opening (Applicable to Positive pressure conveying) high filling efficiency by integrated leakage gas venting.
2. Anti-Blocking design, Ensure safeclly start Even if the Rotary Valve full of material.
3. Outboard Bearing, iongllfe and Excellent performance.
