旋轉閥ZFS
直接聯系
東莞市凌聚機械有限公司
廣東
面議
凌聚
旋轉閥ZFS
1703
ZFS風機直送型旋轉閥/關風機/卸料器
● 適用于≤2kg/cm2系統壓力或壓差的氣流輸送。
● 設置排氣口(正壓輸送時選用)將葉輪旋轉帶出的高壓氣體 通過排氣口送至排氣裝置，提高填充效率。
● 由于空氣貫流，葉片不易附著物料，輸送效率高。
● 空氣輸送用的混相管位于閥體下部，降低了機體額高度。
● 提供鏈驅動、馬達直聯驅動多種安裝形式。
● 能提供各種尺寸的口徑和特殊要求的產品。
ZFS
Pressure Range: ≤2 bar ~ system and different pressure
Main Material: Carbon Steel. Stainless Steel
Drive Mode: Direct Drive/Chain Drive
Specification:
1. Body vent opening (Applicable to Positive pressure conveying) high filling efficiency by integrated leakage gas venting.
2. Because of the air tubular, materials are not easy to attached in the rotor, high conveying efficiency.
3. The mixed-phase pipe used for air transportation at the lower part of the body, Reducing the height of the Body.
