旋轉閥BZGFWK
直接聯系
東莞市凌聚機械有限公司
廣東
面議
凌聚
旋轉閥BZGFWK
1777
BZGFWK防卡型旋轉閥
● 適用于≤2kg/cm2系統壓力或壓差
● 設置排氣口(正壓輸送時選用)將葉輪旋轉帶出的高壓氣體通過排氣口送至排氣裝置，提高填充效率。
● 防切料入口設計，即便上游充滿物料也可安全啟動。
● 軸承外置式安裝、經久耐用、性能優異。
● 提供鏈驅動、直聯驅動多種安裝方式。
● 根據需求配置減速機電機。
● 材質主要有：鑄鋼、不銹鋼系列。
BZGFWK
Pressure Range: ≤2 bar, system and different pressure
Main Material: Cast Steel, Stainless Steel
Drive Mode: Direct Drive/Chain Drive
Specification:
1. Body vent opening (Applicable to Positive pressure conveying), high filling efficiency by integrated leakage gas venting.
2. Anti-Blocking design, Ensure safely start Even if the Rotary Valve full of material.
3. Outboard Bearing, longlife and Excellent performance.
